CUR SENSOR PROG GEN2

The CUR SENSOR PROG GEN2 is an utility board designed for interfacing with XENSIV™ TLE4973/TLE4978 current sensors operating at a 5 V supply level.
评估板

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CUR SENSOR PROG GEN2
CUR SENSOR PROG GEN2

商品详情

  • 分类
    AEC-Q100
  • 应用
    Automotive, Industrial
  • 系列
    Current sensors
推荐的
OPN
CURSENSORPROGGEN2TOBO1
产品状态 active and preferred
英飞凌封装名称 N/A
封装名 N/A
包装尺寸 1
包装类型 CONTAINER
湿度 NA
防潮包装 NON DRY
无铅 No
无卤素 No
符合RoHS标准 Yes
Infineon stock last updated:

产品状态
Active
英飞凌封装名称 N/A
封装名 -
包装尺寸 1
包装类型 CONTAINER
湿度 NA
防潮包装 NON DRY
无铅
无卤素
符合 RoHS 标准
This board is compatible with all TLE4973 (VSON, TISON, TDSO) three-phase and TLE4978 evaluation boards. It supports live current readouts, diagnostics (e.g., OCD check), EEPROM configuration, and calibration. Compatible boards include TLE4978 EVAL 40A, TLE4978 EVAL 50A, TLE4978 EVAL 60A, TLE4973 EVAL LAT BAR (~682 A full sc. rg.), TLE4973 EVAL VER BAR(~920 A full sc. rg.), TLE4973 EVAL STD PCB (~221 A full sc. rg.), TLE4973 EVAL INLAY (~460 A full sc. rg.), TLE4973 EVAL 120 A (~120 A full sc. rg.).

特性

  • Compatible with TLE4973 evaluation boards
  • Compatible with TLE4978 evaluation boards
  • Designed for evaluating three-phase systems
  • Based on XMC1100 microcontroller
  • USB isolator included
  • Real-time GUI provided
  • Supports programming and calibration

产品优势

  • Interfacing with TLE4973/TLE4978 boards
  • Simplifies sensor programming process
  • Enables seamless system integration
  • Compatible with Infineon software tools
