PSOC™ Control C3 Main Line

Unlock real-time control and increased system efficiency with PSOC™ Control C3 Main Line

概述

PSOC™ Control C3 Main Line is based on the Arm® Cortex®-M33, running at 180 MHz, with DSP and FPU capability. In addition to the CPU, the devices contain advanced real-time control peripherals, such as high-performance ADC, comparators,  high-resolution timers and many communication interfaces. Typical applications include HVACs, home appliances, solar, PSUs and EV chargers.

关键特性

  • 180 MHz Arm® Cortex®-M33
  • Up to 256KB read-while-write flash
  • 64KB SRAM with ECC
  • CORDIC math coprocessor
  • 12-Msps, 12-bit "Idle sampling" ADC
  • High resolution PWMs (HRPWM)
  • PSA L2 device security
  • Secure boot
  • 6 power modes with deep sleep

Compare families

Please choose a valid product table template page

Product Table

About

Motor Control (C3M5) and Power Conversion (C3P5)

The Main line of PSOC™ Control C3 offers high performance for motor drive and digital power applications.

PSOC™ Control C3M5 for motor control

C3M5 is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), or requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density.

PSOC™ Control C3P5 for power conversion

C3P5 integrates advanced real-time analog peripherals and a leading-edge digital feature set  to improve efficiency and reliability of new designs.

ModusToolbox™

The leading-edge design environment, ModusToolbox™ allow developers to bring their solutions to market quickly and make the best use of the unique feature set that this product offers.

High Performance Real Time Control

PSOC™ Control C3 Main Line will offer the best performance possible with high real time control capability.  This is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), high efficiency and high power density Switched-mode power supplies (SMPS) or digital power, or any application requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • < 80 ps High Resolution PWM (HRPWM) for period, duty & dead time
  • Real-time control, 16 channels-16 bit and 4 channels-32 bit TCPWMs motor control timers
  • CORDIC math coprocessor
  • Packages:  48, 64, or 80 pins

Security and Safety

Both Safety and Security are fundamental prerequisites for secure, reliable and sustainable industrial applications. It is a must consider for operations, sensitive informations, and authorized control.

PSOC™ Control C3 Main Line offers:

  • Security: PSA L2 certified, Configurable Flash Partitioning / Protection
  • Safety: Class B and SIL 2 compliant safety test libraries

Ease of use for developers

PSOC™ Control C3 is supported by ModusToolbox™, a unified ecosystem platform with tools and software solutions. ModusToolbox™ Motor Suite, and Power Suite are available for developers of PSOC™ Control C3 focus applications. These suites provide a seamless graphical user interface that streamlines evaluation and training, and provide real-time parameter monitoring for valuable insights into performance, efficiency, and reliability. Specialized application environments enable engineers to quickly identify issues, optimize designs, and enhance overall functionality.

ModusToolbox™ software
ModusToolbox™ for motor control
ModusToolbox™ for power conversion
Digital documentation

Getting Started

  • GET the PSOC™ Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
  • DOWNLOAD ModusToolbox™ software
  • READ AN238329 - Getting started with PSOC™ Control C3 MCU on ModusToolbox™ software
PSOC™ Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
ModusToolbox™ software
AN238329 application note

Motor Control (C3M5) and Power Conversion (C3P5)

The Main line of PSOC™ Control C3 offers high performance for motor drive and digital power applications.

PSOC™ Control C3M5 for motor control

C3M5 is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), or requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density.

PSOC™ Control C3P5 for power conversion

C3P5 integrates advanced real-time analog peripherals and a leading-edge digital feature set  to improve efficiency and reliability of new designs.

ModusToolbox™

The leading-edge design environment, ModusToolbox™ allow developers to bring their solutions to market quickly and make the best use of the unique feature set that this product offers.

High Performance Real Time Control

PSOC™ Control C3 Main Line will offer the best performance possible with high real time control capability.  This is ideal for demanding applications which may require dual-motor drive plus Power Factor Correction (PFC), high efficiency and high power density Switched-mode power supplies (SMPS) or digital power, or any application requires Wide Band Gap (WBG) switches such as SiC or GaN for maximum system efficiency and power density

  • 180MHz Arm Cortex M33 with DSP and FPU
  • Memory up to 256KB flash, 64KB SRAM, 16KB I-Cache
  • High performance analog 12-bit, 12 MSPS SAR ADC
  • < 80 ps High Resolution PWM (HRPWM) for period, duty & dead time
  • Real-time control, 16 channels-16 bit and 4 channels-32 bit TCPWMs motor control timers
  • CORDIC math coprocessor
  • Packages:  48, 64, or 80 pins

Security and Safety

Both Safety and Security are fundamental prerequisites for secure, reliable and sustainable industrial applications. It is a must consider for operations, sensitive informations, and authorized control.

PSOC™ Control C3 Main Line offers:

  • Security: PSA L2 certified, Configurable Flash Partitioning / Protection
  • Safety: Class B and SIL 2 compliant safety test libraries

Ease of use for developers

PSOC™ Control C3 is supported by ModusToolbox™, a unified ecosystem platform with tools and software solutions. ModusToolbox™ Motor Suite, and Power Suite are available for developers of PSOC™ Control C3 focus applications. These suites provide a seamless graphical user interface that streamlines evaluation and training, and provide real-time parameter monitoring for valuable insights into performance, efficiency, and reliability. Specialized application environments enable engineers to quickly identify issues, optimize designs, and enhance overall functionality.

ModusToolbox™ software
ModusToolbox™ for motor control
ModusToolbox™ for power conversion
Digital documentation

Getting Started

  • GET the PSOC™ Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
  • DOWNLOAD ModusToolbox™ software
  • READ AN238329 - Getting started with PSOC™ Control C3 MCU on ModusToolbox™ software
PSOC™ Control C3M5 Evaluation Kit (KIT_PSC3M5_EVK)
ModusToolbox™ software
AN238329 application note
