XENSIV™ - 3D Magnetic Sensor for Angle Measurements

This application note gives detailed information about how Infineon's 3D magnetic sensor is eȄective)6 used in angular applications. Based on the angle measurement results of five TLE493D-W2B6 samples it is shown how the angle accuracy is Ȅected by various aspects such as magnet strength, temperature or timing and how the application can be designed for the best performance.

• 887.25 KB
• 09/10/2018
