3 phase bridge driver IC TLE7183F

This Application Note is intended to provide information about the TLE7183F Evaluation Board Revision 1.1. The board is designed to facilitate the evaluation of the Infineon 3 phase bridge driver IC TLE7183F. This document includes a board description, a quick start guide, the schematics and the layout of the board. It is assumed that the reader is familiar with the driver IC data sheet.
