LITIX™ Power TLD5097EP/TLD5098EP/TLD5099EP

This document covers the design steps for a voltage regulator with a DC-DC converter in boost configuration with products provided by Infineon Technologies such as the TLD5099EP. Equations and results can also be applied to TLD5098EP and TLD5097EP. The solution described in the document covers a typical automotive application. However, the system proposed can also be used in all applications where a low voltage power source (such as battery stack or 5 V USB output) has to be boosted to a higher value.

• 550.61 KB
• 10/02/2022
