MOTIX™ TLE987x Verified Chipset application note MOTIX™ TLE987x/OptiMOS™ IAUC100N04S6N022

The purpose of this document is to provide a limited number of verified driver/MOSFET combinations with a best fit driver configuration that can be used to achieve good system performance. Following the guidance provided in this report, you will see a proposal for the schematics in the B6 bridge of your motor control unit. For this schematics proposal, you can select one of four OptiMOS™ 6 MOSFETs, ranging from 1.0mΩ to 2.8mΩ, depending on your application needs. For each possible MOSFET selection, a dedicated gate driver configuration is provided, which was tested for a wide range of conditions. For these specific combinations and configurations, you will then get detailed information on the switching characteristics.

• 7.10 MB
• 12/03/2024
