CYT4DNJBRCQ1BZSGS
CYT4DNJBRCQ1BZSGS
每件.

商品详情

  • 16bit TCPWM
    50
  • 16bit TCPWM (Motor control)
    0
  • 2.5 D Engine (IRIS on-the-fly)
    Yes
  • 32bit TCPWM
    32
  • ADC Channel
    48
  • ASIL/SIL support
    ASIL-B
  • CAN-FD
    4
  • CXPI
    2
  • DMA Channels
    76/84/8
  • eMMC IO speed
    NA
  • eMMC
    0
  • eSHE/HSM
    HSM
  • GPIO
    168
  • I2S
    4
  • JPEG Decoder
    1
  • LCD Direct Drive
    NA
  • LIN
    2
  • LPDDR4/DDR3 PHY
    NA
  • LVDS TX PHY
    2 x single / 1 x dual
  • MIPI D-PHY
    1
  • MPU
    Yes
  • PPU
    PPU
  • RC-OSC
    Yes
  • RTC channel
    1
  • SCB Blocks
    12
  • SMIF (SPI/HyperBus)
    2
  • SMIF speed
    200MHz
  • SRAM
    640 kByte
  • VRAM Protection
    Yes
  • Work Flash
    128 kByte
  • Main Core type/Crypto Core type
    ARM_CM7F (Dual core with FPU)/CM0+
  • Main Core frequency
    320 MHz
  • Ethernet Ports
    1
  • Ethernet speed
    10/100/1000
  • Supply Voltage
    2.7 to 5.5 V
  • Classification
    ISO 26262-compliant
  • Graphics
    Yes
  • External Interrupt channel
    168
  • Operating temperature range TA
    -40°C - 105°C
  • Pin Count
    327 Pins
  • VRAM
    4MB
  • Smart IOs
    8
  • Floating Point Unit
    Double precision
  • Temperature sensor
    Y
  • Watchdog
    Yes
  • Drawing engine
    Yes
  • Cybersecurity Classification
    ISO 21434-ready
  • Video-In
    1
  • Video-out
    2
  • Debug Interface
    SWD/JTAG/Trace
  • Flash Security
    Yes
  • Flash
    6336 kByte
OPN
CYT4DNJBRCQ1BZSGS
产品状态 active and preferred
英飞凌封装名称
封装名 FBGA-327 (002-28943)
包装尺寸 900
包装类型 TRAY
湿度 3
防潮包装 DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:
每件. 有存货

产品状态
Active
英飞凌封装名称
封装名 FBGA-327 (002-28943)
包装尺寸 900
包装类型 TRAY
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准
每件.
有存货
CYT4DNJBRCQ1BZSGS 属于 TRAVEO ™ T2G CYT4DN 系列微控制器。 它基于高效嵌入式处理器 Arm Cortex-M7,并结合了 2.5D 图形引擎、声音处理和 Arm ® Cortex ® -M0+ CPU 用于外围设备和安全处理。 此外,它还包括一个 WVGA GFX 和一个 PG-LFBGA-327 封装。它专用于仪表盘和平视显示器 (HUD) 等汽车系统。

特性

  • 320-MHz Arm ® Cortex ® -M7F 双
  • 6336KB 代码闪存、128KB 工作闪存
  • 640 KB SRAM
  • 2.7 至 5.5 电源电压
  • HSM(硬件安全模块)
  • 168x 可编程 GPIO
  • 12x SCB / 2x LIN / 4x CAN FD 通道
  • 172x DMA 通道
  • -40°C - +125°C 温度范围
  • 327-BGA 封装

产品优势

  • 高达 1280 x 480 的图形解决方案
  • 支持 ASIL-B 设计
  • A/B 交换软件无线更新支持
  • 一流的功耗
  • 适用于各种应用的集群 MCU 产品组合
  • 高水平的图形软件重用
