现货,推荐
符合RoHS标准

BUY25CS45B-01 (ES)

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

BUY25CS45B-01 (ES)
BUY25CS45B-01 (ES)

商品详情

  • ESD Class
    class 1C
  • ID max
    45 A
  • IDpuls
    180 A
  • Ptot max
    208 W
  • QG
    70 nC
  • QPL Part Number
    5205/030/03
  • RDS (on) max
    50 Ω
  • TID max
    100 Krad(Si)
  • VBRDSS
    250 V
  • VDS
    250 V
  • VF max
    1.4 V
  • VGS
    +/-20 V
  • Download Model
    https://www.infineon.com/api/redirect/ispn/BUY25CS45B-01 (ES)/#!simulation
  • Product Category
    Rad tol MOSFETs
  • Optional TID Rating (kRad(si))
    100
  • Comments
    Package TO254AA
  • Package
    TO-254AA
  • Polarity
    N
  • Generation
    PowerMOS
  • Die Size
    3
  • Qualification
    ESA
  • Language
    SPICE
OPN
BUY25CS45B01ESX1SA1
产品状态 active and preferred
英飞凌封装名称 N/A
封装名 N/A
包装尺寸 1
包装类型 WAFER SAWN
湿度 N/A
防潮包装 DRY
无铅 No
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:

产品状态
Active
英飞凌封装名称 N/A
封装名 -
包装尺寸 1
包装类型 WAFER SAWN
湿度 -
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准
抗辐射电源开关 250V/45A

特性

  • 低 RDS(on)
  • 单粒子效应 (SEE) 加固
    LET 85,范围:118μm VGS = -10V,VDS = 250V,已获批准
    LET 55;范围:90µm VGS = -15V,VDS = 250V,已获批准
  • 总电离剂量 (TID) 加固 100 kRad,已获批准(R 级)
  • 全密封
  • N 沟道
