现货,推荐
符合RoHS标准
无铅

CY8C4125PVE-S422

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY8C4125PVE-S422
CY8C4125PVE-S422

商品详情

  • ADC (#, Max. Resolution @ Sample Rate)
    SAR (1, 12-bit @ 806 ksps)
  • CAN
    0
  • CAPSENSE™
    No
  • CPU
    ARM Cortex-M0+
  • ECO
    No
  • GPIOs
    24
  • LCD Direct Drive
    Yes
  • LP Comparators
    2
  • SCB Blocks
    2
  • SRAM
    4 kByte
  • TCPWM Blocks
    5
  • USB Full Speed
    0
  • USB Type
    None
  • WCO
    No
  • Classification
    ISO 26262-ready
  • Publish in NPSG
    Y
  • Publish in PSG
    Y
  • Peak Reflow Temp
    260 °C
  • Operating Temperature
    -40 °C to 125 °C
  • Operating Voltage
    1.71 V to 5.5 V
  • Lead Ball Finish
    Ni/Pd/Au
  • Smart IOs
    16
  • Comparators
    2
  • Family
    PSOC™ Automotive 4100S
  • Operational Amplifier
    2
  • Universal Digital Blocks
    0
  • Flash
    32 kByte
  • Frequency max
    24 MHz
OPN
CY8C4125PVE-S422
产品状态 active and preferred
英飞凌封装名称
封装名 SSOP-28 (51-85079)
包装尺寸 1175
包装类型 TUBE
湿度 3
防潮包装 DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:

产品状态
Active
英飞凌封装名称
封装名 SSOP-28 (51-85079)
包装尺寸 1175
包装类型 TUBE
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准

特性

  • 符合 AEC-Q100 标准
  • 频率高达 24MHz
  • 闪存 32KB
  • SRAM 4KB
  • CAPSENSE ™
  • 12 位 SAR ADC (806 Ksps)
  • 24 个 GPIO、24xSCB 模块
  • 直接 LCD驱动器
  • 温度:-40 至 +105C
  • 封装:28-SSOP

产品优势

  • 低功耗计算与集成
  • MCU 中的差异化触摸 HMI 功能
  • 支持电阻式和电流感应
  • 高速通信:快速 I2C/CAN-FD
  • 通过加密支持提高安全性
  • 易于使用的原型应用程序软件
