CY8C6347BZI-BLD43
CY8C6347BZI-BLD43
每件.
数据手册

商品详情

  • ADC (#, Max. Resolution @ Sample Rate)
    SAR (1, 12-bit @ 1 msps)
  • Number of ADC Modules
    1
  • BLE RX Sensitivity
    -95 dBm
  • BLE Power Output
    4 dBm
  • BLE Supported Frequency band
    2.40 GHz
  • BLE Maximum Data Rate
    2 MBit/s
  • CAN
    0
  • CAPSENSE™
    Y
  • CPU
    ARM Cortex-M4
  • DAC (#, Max. Resolution @ Sample Rate)
    (1,12-bit @ 200 ksps)
  • DMA Channels
    32
  • FS-USB
    None
  • GPIOs
    78
  • I/O Pins (Smart)
    16
  • I/O Pins
    78
  • I2S
    1
  • LCD Direct Drive
    Y
  • PDM-PCM
    2
  • SRAM
    288 kByte
  • Serial Communication Blocks
    9
  • Cryptographics Accelerator
    (AES, 3DES, RSA, SHA-512, SHA-256 and ECC)
  • Quad-SPI
    Y
  • Publish in NPSG
    Y
  • Publish in PSG
    Y
  • Timer/Counter/PWM Blocks
    32
  • Peak Reflow Temp
    260 °C
  • Operating Temperature
    -40 °C to 85 °C
  • Operating Voltage
    1.7 V to 3.6 V
  • Lead Ball Finish
    Sn/Ag/Cu
  • Secondary Core
    ARM Cortex-M0
  • Comparators
    2
  • Family
    PSOC™ 63
  • Operational Amplifier
    0
  • Universal Digital Blocks
    0
  • Flash
    1024 kByte
  • Frequency max
    150 MHz
受到推崇的
OPN
CY8C6347BZI-BLD43
产品状态 active and preferred
英飞凌封装名称
PG-VFBGA-116
封装名 WFBGA-116 (002-16574)
包装尺寸 3640
包装类型 TRAY
湿度 3
防潮包装 DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:
 每件. 有存货

产品状态
Active
英飞凌封装名称
PG-VFBGA-116
封装名 WFBGA-116 (002-16574)
包装尺寸 3640
包装类型 TRAY
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准
每件.
有存货
