现货,推荐
符合RoHS标准

TLE42764GV

TLE42764GV 是一款单片集成低压差稳压器,负载电流高达 400 mA。
每件.
有存货

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

TLE42764GV
TLE42764GV
每件.

商品详情

  • Hold
    no
  • Accuracy
    2 %
  • Dropout Voltage
    250 mV
  • Enable (=Inhibit)
    yes
  • Base Product
    TLE42764
  • Reset
    no
  • Operating Temperature
    -40 °C to 150 °C
  • Operating Voltage
    4.5 V to 40 V
  • Status Output
    no
  • Power Fail
    no
  • Power Good
    no
  • Watchdog
    no
  • Family
    OPTIREG™ linear General Purpose
  • Currently planned availability until at least
    2038
  • Qualification
    Automotive
  • Regulator Type
    General Purpose
  • Output Voltage Type
    adj.
  • Output Current max
    400 mA
  • Over Voltage Protection
    no
  • Quiescent Current
    100 µA
  • Budgetary Price €/1k
    0.82
  • Early Warning
    no
OPN
TLE42764GVATMA1
产品状态 active and preferred
英飞凌封装名称
封装名 N/A
包装尺寸 1000
包装类型 TAPE & REEL
湿度 1
防潮包装 NON DRY
无铅 No
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:
每件. 有存货

产品状态
Active
英飞凌封装名称
封装名 -
包装尺寸 1000
包装类型 TAPE & REEL
湿度 1
防潮包装 NON DRY
无铅
无卤素
符合 RoHS 标准
每件.
有存货
该设备专为汽车应用的恶劣环境而设计。

特性

  • 极低电流消耗
  • 可调和 5 V 固定输出电压 ±2%
  • 输出电流高达 400 mA
  • 使能输入
  • 极低压差
  • 输出电流限制
  • 反极性保护
  • 宽温度范围:-40°C 至 150°C
  • 绿色产品(符合 RoHS 标准)
  • 符合 AEC 认证

产品优势

  • 强大的保护功能
  • 宽输入和温度范围操作
