Automotive EasyPACK™ Power Modules

The Automotive EasyPackTM power module is a simple to use power module in combination with a printed circuit board. It is an indirectly cooled power package, where the thermal pad is mounted onto the cooler and the signal pins, as well as the power pins, are connected to a printed circuit board. In comparison to other power module solutions on the market, the output currents of the Automotive EasyPackTM power module are routed to the load via a printed circuit board. Within this document, you will find mounting recommendations and assembly instructions of the Infineon Automotive EasyPackTM power module as well as information on the PressFIT technology.

• 1.15 MB
• 21/04/2022
