现货，推荐

5962F1120202VXA

数据手册
封装

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

5962F1120202VXA
5962F1120202VXA
数据手册

商品详情

  • ECC
    N
  • Density
    72 MBit
  • Peak Reflow Temp
    220 °C
  • Operating Temperature
    -55 °C to 125 °C
  • Operating Voltage
    1.7 V to 1.9 V
  • Lead Ball Finish
    Sn/Pb
  • Interfaces
    Parallel
  • Data Width
    x 36
  • Architecture
    QDR-II+
  • On-Die Termination
    N
  • Family
    QDR-II+
  • Organization (X x Y)
    2Mb x 36
  • Burst Length (Words)
    4
  • Currently planned availability until at least
    2033
  • Qualification
    Military
  • Device weight
    6152.8 mg
  • Read Latency (Cycles)
    2
  • Bank Switching
    N
  • Frequency
    250 MHz
受到推崇的
OPN
5962F1120202VXA
产品状态 active and preferred
英飞凌封装名称
C-CGA-165
封装名 CCGA-165 (001-58969)
包装尺寸 1
包装类型 TRAY
湿度 1
防潮包装 NON DRY
无铅 No
无卤素 No
符合RoHS标准 No
Infineon stock last updated:

产品状态
Active
英飞凌封装名称
C-CGA-165
封装名 CCGA-165 (001-58969)
包装尺寸 1
包装类型 TRAY
湿度 1
防潮包装 NON DRY
无铅
无卤素
符合 RoHS 标准
