现货,推荐
符合RoHS标准
无铅

CY8C4126AZS-M445T

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CY8C4126AZS-M445T
CY8C4126AZS-M445T

商品详情

  • ADC (#, Max. Resolution @ Sample Rate)
    SAR (1, 12-bit @ 806 ksps)
  • CAN
    0
  • CAPSENSE™
    Yes
  • CPU
    ARM Cortex-M0
  • DMA Channels
    8
  • ECO
    No
  • EEPROM
    0 kByte
  • GPIOs
    51
  • I/O Pins
    51
  • I/O Pins (SIO)
    0
  • JTAG and Si ID
    0x11C3
  • LCD Direct Drive
    Yes
  • LP Comparators
    2
  • SCB Blocks
    4
  • SRAM
    8 kByte
  • TCPWM Blocks
    8
  • USB I/O
    0
  • USB Full Speed
    0
  • USB Type
    None
  • WCO
    Yes
  • Serial Communication Blocks
    4
  • Classification
    ISO 26262-ready
  • Publish in NPSG
    Y
  • Publish in PSG
    Y
  • Timer/Counter/PWM Blocks
    8
  • Peak Reflow Temp
    260 °C
  • Operating Temperature
    -40 °C to 105 °C
  • Operating Voltage
    1.71 V to 5.5 V
  • Lead Ball Finish
    Pure Sn
  • Required Kit
    None
  • Smart IOs
    0
  • Analog Blocks (Universal)
    0
  • Comparators
    2
  • On-chip Clock Generation (PLL)
    N
  • Family
    PSOC™ 4100M
  • Operational Amplifier
    2
  • Continuous Time Blocks
    1
  • Universal Digital Blocks
    0
  • Flash
    64 kByte
  • Frequency max
    24 MHz
OPN
CY8C4126AZS-M445T
产品状态 active and preferred
英飞凌封装名称
封装名 TQFP-64 (51-85051)
包装尺寸 1500
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:

产品状态
Active
英飞凌封装名称
封装名 TQFP-64 (51-85051)
包装尺寸 1500
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准

特性

  • 符合 AEC-Q100 标准
  • 频率高达 24 MHz
  • 闪存 64KB
  • SRAM 8 KB
  • CAPSENSE ™
  • 12 位 SAR ADC (806 Ksps)
  • 51 个 GPIO、24xSCB 模块
  • 直接 LCD驱动器
  • 温度:-40 至 +105C
  • 封装:PG-TQFP-64

产品优势

  • 低功耗计算与集成
  • MCU 中的差异化触摸 HMI 功能
  • 支持电阻式和电流感应
  • 高速通信:快速 I2C/CAN-FD
  • 通过加密支持提高安全性
  • 易于使用的原型应用程序软件
