现货,推荐
符合RoHS标准

FS3L40R07W2H5F_B70

650 V、40 A 三电平 IGBT 模块
每件.
有存货

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

FS3L40R07W2H5F_B70
FS3L40R07W2H5F_B70
每件.

商品详情

  • IC(nom) / IF(nom)
    40 A
  • IC max
    40 A
  • VCE(sat) (Tvj=25°C typ)
    1.32 V
  • VCES / VRRM
    650 V
  • VF (Tvj=25°C typ)
    1.65 V
  • Housing
    EasyPACK™ 2B
  • Dimensions (width)
    48 mm
  • Dimensions (length)
    62.8 mm
  • Technology
    IGBT5 - H5,Silicon Carbide Schottky Diode
  • Features
    PressFIT, AlN
  • Voltage Class max
    650 V
  • Qualification
    Industrial
  • Configuration
    3-level
OPN
FS3L40R07W2H5FB70BPSA1
产品状态 active and preferred
英飞凌封装名称 AG-EASY2B-7011
封装名 N/A
包装尺寸 15
包装类型 TRAY
湿度 NA
防潮包装 NON DRY
无铅 No
无卤素 No
符合RoHS标准 Yes
Infineon stock last updated:
每件. 有存货

产品状态
Active
英飞凌封装名称 AG-EASY2B-7011
封装名 -
包装尺寸 15
包装类型 TRAY
湿度 NA
防潮包装 NON DRY
无铅
无卤素
符合 RoHS 标准
每件.
有存货

特性

  • CoolSiC ™肖特基二极管第 5 代
  • 阻断电压能力提升至 650 V
  • AlN DCB 具有更佳的热导率

产品优势

  • 启用更高频率
  • 出色的模块效率
  • 系统效率提升
  • 系统成本优势
  • 降低冷却要求
  • 更长的使用寿命和/或更高的功率密度
