IPD60R180CM8

IPD60R180CM8 - 600 V CoolMOS ™ 8 功率晶体管
每件.
有存货

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

IPD60R180CM8
IPD60R180CM8
每件.

商品详情

  • ID (@25°C) max
    15 A
  • IDpuls max
    48 A
  • QG
    17 nC
  • QG (typ @10V)
    17 nC
  • RDS (on) (@10V) max
    180 mΩ
  • RDS (on) max
    180 mΩ
  • VDS max
    600 V
  • VGS(th)
    4.2 V
  • Mounting
    SMT
  • Package
    DPAK
  • Operating Temperature
    -55 °C to 150 °C
  • Polarity
    N
  • Budgetary Price €/1k
    0.62
OPN
IPD60R180CM8XTMA1
产品状态 active and preferred
英飞凌封装名称 PG-TO252-3
封装名 N/A
包装尺寸 2500
包装类型 TAPE & REEL
湿度 1
防潮包装 NON DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:
每件. 有存货

产品状态
Active
英飞凌封装名称 PG-TO252-3
封装名 -
包装尺寸 2500
包装类型 TAPE & REEL
湿度 1
防潮包装 NON DRY
无铅
无卤素
符合 RoHS 标准
每件.
有存货
600 V CoolMOS ™ 8 SJ MOSFET 系列是 600 V CoolMOS ™ 7 MOSFET 系列(包括 P7、S7、CFD7、C7 (G7) 和 PFD7)的后续产品。它的栅极电荷 (Qg) 比 CFD7 降低了 20%,关断损耗 (Eoss) 比 CFD7 进一步降低了 12%,反向恢复电荷 (Qrr) 与 CFD7 相比降低了 3%,并且具有市场上最低的反向恢复时间 (trr)。

特性

  • 一流的 RDS(on)*A
  • 大幅减少损失
  • 出色的换向坚固性
  • 集成快速体二极管
  • .XT 互连
  • ESD 保护

产品优势

  • 提高功率密度
  • 易于使用且设计快速
  • 低振铃趋势
  • 简化热管理
  • 简化投资组合
  • SMT 兼容
