现货,推荐
符合RoHS标准

CYBT-423054-02

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

CYBT-423054-02
CYBT-423054-02

商品详情

  • Longevity - 15 years
    Yes
  • ADC (#, Max. Resolution @ Sample Rate)
    SD(1, 12bit ENoB (audio), 10 bit ENoB (DC), 12MHz Clock)
  • CAPSENSE™
    No
  • CPU Core
    96MHz
  • GPIOs
    17
  • I2C
    1
  • PDM
    1
  • PWM
    6
  • ROM
    2MB
  • SPI
    2
  • SRAM
    512 kByte
  • UART
    2
  • V
    1.76 V to 3.63 V
  • Serial Communication Blocks
    0
  • Main CPU Core
    Arm® Cortex®- M4
  • Longevity - Extended
    No
  • Launch Date
    31-03-2020
  • Base Silicon
    CYW20719
  • Type of Antenna
    Chip Antenna
  • Size (X mm x Y mm x Z mm)
    11 x 11 x 1.70 mm
  • Operating Temperature
    -30 °C to 85 °C
  • Extended Range
    No
  • Pads
    24
  • Family
    AIROC™ Bluetooth Modules
  • Bluetooth EDR 2MBPS RX SENSITIVITY
    –94.0 dBm
  • Bluetooth EDR 2Mbps TX POWER
    0 dBm
  • Bluetooth LE RX Sensitivity
    - 95.0 dBm
  • Bluetooth LE TX Power
    4 dBm
  • Bluetooth LE Data rate
    2 MByte/s
  • Bluetooth LE
    Yes
  • Bluetooth Classic
    Yes
  • Currently planned availability until at least
    31-03-2035
  • Secondary CPU Core
    None
  • Operational Amplifier
    No
  • Flash
    1024 kByte
OPN
CYBT-423054-02
产品状态 active and preferred
英飞凌封装名称
封装名 MODULE-28 (002-23238)
包装尺寸 500
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅 No
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:

产品状态
Active
英飞凌封装名称
封装名 MODULE-28 (002-23238)
包装尺寸 500
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准
