SAK-XC2785X-104F80LR AB

停产

Content could not be loaded

Unfortunately, we were unable to load the content for this section. You may want to refresh the page or try again later.

SAK-XC2785X-104F80LR AB
SAK-XC2785X-104F80LR AB

商品详情

  • A/D Input Lines (incl. FADC)
    24
  • Number of ADC Modules
    2
  • CAN Nodes
    2
  • DMA Channels
    8
  • DSP Functionality
    yes
  • EEPROM Emulation (Data-Flash)
    yes
  • I/O Operation Voltages
    3.3 V
  • SRAM (incl. Cache)
    50 kByte
  • Serial I/O Interfaces
    4
  • Type of Serial I/O Interfaces
    UART
  • Additional Features
    no
  • Power Mode
    3
  • External Bus Interface
    yes
  • Type of Memory
    Flash
  • Timed I/O Pins (PWM, CAPCOM)
    44
  • Real Time Clock
    yes
  • Fast Flash Programming
    no
  • Instruction Width ([bits])
    16/32
  • Oscillator Watchdog
    yes
  • Digital I/O Pins
    116
  • Floating Point Unit
    no
  • Temperature
    -40 to 125°C
  • On-chip Clock Generation
    yes
  • On-chip Voltage Regulator
    yes
  • Watchdog Timer
    yes
  • Program Memory
    832 kByte
  • Touch/LED Matrix Control
    no
  • Timer/Counter
    17
  • Qualification
    Automotive
  • Budgetary Price €/1k
    8.55
OPN
XC2785X104F80LRABKXUMA1
产品状态 discontinued
英飞凌封装名称
封装名 N/A
包装尺寸 1000
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅 Yes
无卤素 Yes
符合RoHS标准 Yes
Infineon stock last updated:

产品状态 discontinued
英飞凌封装名称
封装名 -
包装尺寸 1000
包装类型 TAPE & REEL
湿度 3
防潮包装 DRY
无铅
无卤素
符合 RoHS 标准
该微控制器配备了先进的外设,如多个 PWM 单元、灵活的串行接口(通用串行接口)以及具有最多 2 个 CAN 节点的 MultiCAN 单元,是价值驱动的 PowerTrain 应用的理想选择。此外,它还集成了嵌入式电压调节器、带有附加闪存模块的 EEPROM 仿真以及各种片上振荡器等外部组件,以进一步优化总系统成本。

特性

  • 封装:PG-LQFP-144
  • CAN 节点:2
  • 程序内存:832.0 KByte
  • FlexRay ™ :无
  • 串行 I/O 接口类型:USIC
